激光封焊机

主要技术参数：

	LW300A	LW400A	LW500A	LW600A
Wavelength	1064nm
Average Power	300W	400W	500W	600W
Pulse Energy @ 10mS	50J	80J	80J	100J
Peak Power	5.0KW	8.0KW	8.0KW	10.0KW
Pulse Width Range	(≥5.0ms:0.1ms/step) 0.25 to 99.9 ms(<5.0ms:0.05ms/step)
Repetition Rate	500Hz
Pulse Shaping Feature	Yes
Aiming Laser	Diode
Number of Outputs	Up to 4
Energy Share 0utputs	One group of up to 4,or two groups of 2
Time Share outputs	Up to 4
Fiber Core Diameter (Sl or Gl fibers)	0.3,0.4,0.6,0.8,1.0mm	0.4,0.6,0.8,1.0mm	0.3,0.4,0.6,0.8,1.0mm	0.4,0.6,0.8,1.0mm
Datacom	8/7 data, 2/1 stop bits, even/odd parity, RS485/422
Power Requirements	220VAC+10%/-15%, 3Phase, 50/60Hz
Line Current	43A		84A
Cooling Method	Water-Water
External Cooling Water Requirements	4.2 gal/min. (16 liters/min)@86°F(30℃) 6.6 gal/min. (25 liters/min)@95°F(35℃) 1 bar(14.7 psi) minimum differential pressure 3 bar(44.1 psi) maximum inlet pressure		6.6 gal/min. (25 liters/min)@77°F(25℃) 14.5 gal/min. (55 liters/min)@90°F(32℃) 1 bar(14.7 psi) minimum differential pressure 3 bar(44.1 psi) maximum inlet pressure
Cooling Water Inlet Diameter	0.591 inch(15mm)		0.748 inch(19mm)
Ambient Operating Temperature	40-95°F (5-35℃)
Humidity	85% non-condensing @77°F (25℃)
Physical Dimensions H*W*D inches (mm)	46.1×20.9×53.1(1170×530x1350)		47.2x21.6x70.1(1200x550x1780)
Weight Ibs. (Kg)	882(400)	992(450)	1191(540)
Special Features	CE certified units available: please consult factory
BTU/Hr@ 100% Duty Cycle (Minimum Req.)	40,300 (3.5)		59,400 (5)
